dsh-plugin-mascot

English | 中文

A mascot for the DeepSeek Harness (DSH) Web GUI. It sits in the bottom-right corner. Click it and a panel opens with the session's token cost and cache performance.

The image above is lib/client.js running in Chromium with the built-in placeholder, i.e. a fresh clone before npm run fetch-art. With the official artwork installed it looks like docs/preview-official.png, which is generated locally and not committed.

What the panel shows

• Token cache-hit rate: cache reads over all billed input
• Token breakdown: uncached input, cache read, cache write, output, session total
• Context occupancy: current usage against the context window
• Account balance: fetched host-side, so the API key stays in the host process
• Music: the character's Siren Records album, or a 30-second official preview
• Character and look: 9 characters, 22 looks

Install

DSH Desktop loads plugins through the profile's cordis.patch.yml. cordis.yml is rewritten to [] on every boot; do not edit it.

The plugin has no runtime dependencies. Two ways in, pick one.

Option A: point at the file directly.

# ~/.dsh/profiles/desktop/cordis.patch.yml
- insert:
    - id: mascot
      name: 'file:///C:/Users/<you>/Desktop/kexier/dsh-plugin-mascot/lib/index.js'

The file: URL names a file, not the folder. A relative path also works and resolves against the patch file's directory.

Option B: install it as a profile dependency.

dsh plugin --profile desktop add "/absolute/path/to/dsh-plugin-mascot"
dsh plugin --profile desktop add link:/absolute/path/to/dsh-plugin-mascot
dsh plugin --profile desktop add "github:ZYAONS/dsh-plugin-mascot"

- insert:
    - id: mascot
      name: dsh-plugin-mascot

Add config to either form:

- insert:
    - id: mascot
      name: dsh-plugin-mascot
      config:
        baseUrl: 'https://api.deepseek.com'
        cacheTtlMs: 30000

Restart DSH Desktop. The desktop composes its patch layers once per launch and does not watch the profile directory. Reloading the page is not enough. After the first mount, edits to lib/client.js hot-reload without another restart.

Console

Configure the plugin in a browser before installing anything:

https://zyaons.github.io/dsh-plugin-mascot/

Seven sections:

• 00 Live preview: the mascot, animated, wearing the look you picked
• 01 Plugin: plugin on/off, balance lookup on/off
• 02 Character: one card per character
• 03 Looks: tick which artwork may appear
• 04 Motion: bone rig, multi-frame looks
• 05 Output: a cordis.patch.yml to copy or download
• 06 Install: five steps, including fetching artwork and restarting

The page is static, runs on GitHub Pages, and reads nothing from your machine. State lives in localStorage. ?theme= and ?character= deep-link both, and ?theme= also selects the character.

Served by the plugin at /dsh-mascot/console/ it also reads the artwork on your own machine.

Themes

10 page themes: a neutral one plus one per character.

• 中性 auto: silver, square corners
• 可露希尔: blue, square
• 千石由乃: magenta, 14px
• 缪尔赛思: light green, 10px
• 丰川祥子: violet, 8px
• 谬因: deep green, 14px
• 予愿安洁莉娜: cyan, 10px
• 夕: teal, 10px
• 结城理: P3R blue, square
• 望: bone, square

Picking a character's theme selects that character, and picking a character selects its theme. The neutral theme belongs to no character; it is the only one that can disagree with the artwork, and it hides the music row.

Language

The console is English. The panel is Chinese. art/looks.json carries nameEn / roleEn / taglineEn beside name / role / tagline, and build-site.mjs copies the English set into the catalogue. check-site fails if a rendered record has no translation, or if Chinese reappears outside the rights notice.

Characters and looks

All artwork belongs to Hypergryph or Bushiroad. The repository ships the declaration, not the images.

npm run fetch-art              # download, cut out where needed, re-index
npm run fetch-art -- --force   # re-download regardless of hash

Nine characters, 22 looks:

• 可露希尔 Closure: chibi, portrait
• 千石由乃 Yuno: chibi in two drawn poses, anime, casual
• 缪尔赛思 Muelsyse: chibi, alt, portrait
• 丰川祥子 Sakiko: anime, casual, collab chibi
• 谬因 Miuyin: chibi, portrait
• 予愿安洁莉娜 Yuyuan: chibi, portrait
• 夕 Dusk: chibi, portrait
• 结城理 Makoto: portrait, collab chibi, P3R
• 望 Wang: chibi, portrait

Seven are Arknights; Yuno and Sakiko are BanG Dream!. Sakiko and Makoto are collab designs. art/looks.json is hand-written and art/index.json is generated; every entry carries source URLs and a sha256, checked on download.

To add a look, add an entry to looks in art/looks.json and run npm run fetch-art. No code changes.

scripts/art-sync.mjs measures each image's alpha bounding box in a browser, derives the framing for both seats (104×172 sprite, 38×50 portrait), and samples an accent colour. The results go into art/index.json, which the host half filters to what is on disk and serves to the browser.

npm run art:watch re-indexes whenever a file lands in art/.

A missing file falls back to a neutral placeholder: a dashed box with a generic glyph. It depicts no character.

Motion

Three layers. The first two are motion; the third is the browser playing a file.

Skeletal animation

A 2D bone and skinned-mesh renderer in WebGL2.

• art-sync measures each image's silhouette profile as 32 horizontal bands. The client finds the neck from the band where the silhouette pinches.
• Seven bones: root at the feet, spine at the hip, neck at the neck, armL/armR at the shoulders, foreL/foreR at the elbows. Children inherit parent transforms.
• Vertex weights are distributed vertically, blended across a band at each joint. The arms are separate regions, masked to their own side of the centre line.
• The texture is uploaded with UNPACK_PREMULTIPLY_ALPHA_WEBGL.
• A click adds a decaying oscillation that ends within 1.6 s.

If WebGL2 is unavailable, a shader fails to compile, or the image taints the canvas, it renders a plain <img>. The rig can only add motion. The preview script prints rig: ON (canvas 140x232) to report which path ran.

Measured motion

The idle, greeting and walk come from the games' own Spine models, mirrored by Ark-Models and read with the official 3.8 runtime.

npm run measure:motion                            # all six animations
npm run measure:motion -- --model=4228_closur --character=closure
npm run measure:motion -- --model=4228_closur --moves

Arknights chibi have six animations: Default, Interact, Move, Relax, Sit, Sleep. All six are measured for all 8 characters that have a model; art/motion.json is keyed by character. Three are used:

• Relax as the idle: waist 0.4°, forearm 28.6°
• Interact as the greeting: waist 17.6°, forearm 79.5°
• Move as the walk-in on a look change: IK feet ±89 units

Sit and Sleep carry almost no motion in either channel. Sleep moves three bones by at most 2.2 units, Sit's largest translation is an eyeball, and Default is a zero-length animation. They are measured and not inlined.

npm run motion:literal    # regenerate the inlined block in lib/client.js

The generated block ships idle, greet, move and the blink per character. A character with no entry falls back to the default.

A character that declares gesture: "evoker" raises its right arm to its temple on click: the upper arm turns 140°, the forearm folds 120°.

Multi-frame animation

Yuno's Q-version is two drawn poses in one sheet. cutout.mjs splits them, crops each to its own bounding box, and gives both one shared scale. The browser cross-fades every 5.2 s. It stands down when the bone rig is on.

Any frame that is a GIF or animated WebP plays on its own.

Music

The panel plays the character's Siren Records album through a hotlinked official CDN. art/siren.json maps a character to the album for the event they came from; art/songs.json covers characters with a 30-second Apple Music preview and no Siren release.

npm run siren:sync            # re-resolve albums and previews
npm run siren:sync -- --list

No audio file is stored. The host serves both maps through /api/looks.

Rooms

Each character's dock has a backdrop: a room the plugin draws from gradients, or official furniture art.

npm run fetch-rooms            # download what is missing
npm run fetch-rooms -- --list  # show the declaration
npm run fetch-rooms -- --force # re-download

Images go to art/room-<character id>.<ext>. The host finds them by filename, so a restart is all that is needed. art/rooms.json declares which set each one is and where it came from. Deleting art/room-* returns the character to the drawn room.

Usage

• Click the sprite to toggle the panel.
• The 角色 row switches character; the 形象 row switches that character's look. A 动态 badge marks a multi-frame look.
• The 动效 row toggles the bone rig. The music row's ▶ plays or stops the album.
• 刷新 re-reads the balance. Click the backdrop or press Esc to close the panel.

The choice is stored in localStorage. With the system's reduce-motion preference set, all animation stops.

The pill under the sprite shows three figures. 余额 ¥128.42 is the account balance, fetched host-side; when the lookup fails it reads 点我 Token / 余额 instead. 命中 89.0% is this session's cache hit rate. 今天 1.2M is the tokens spent today on this machine.

The daily figure needs the host to keep books: a session that ended an hour ago takes its numbers with it. The host keeps .cache/usage-daily.json, keyed by session, and stores a high-water mark per session. The browser reports a cumulative total repeatedly, so re-reporting adds nothing; a total that goes backwards never subtracts. Midnight resets it.

Configuration

Every field has a default.

Field	Default	Meaning
routePrefix	/dsh-mascot	path prefix claimed on the host webserver
baseUrl	https://api.deepseek.com	provider origin hosting the balance endpoint
apiKeyRef	DEEPSEEK_API_KEY	credentials reference in ~/.dsh/.credentials.yaml
cacheTtlMs	60000	freshness of a balance answer; failures are never cached
timeoutMs	10000	upstream request budget
allowForeignBaseUrl	false	allow the API key to go to a baseUrl that is not DeepSeek's own host
artDir	the plugin's own art/	directory holding the artwork

Behind a proxy or self-hosted gateway, point baseUrl at it and set allowForeignBaseUrl: true. Without that flag the plugin refuses to send the key to any other host, and says which host it refused. The gateway must implement GET /user/balance.

Layout

dsh-plugin-mascot/
├── lib/
│   ├── index.js        host half: the /dsh-mascot routes
│   └── client.js       browser half: sprite, panel, themes, renderer, music
├── art/
│   ├── looks.json      characters, themes, urls, hashes
│   ├── index.json      generated by art-sync
│   ├── motion.json     generated by measure-motion, keyed by character
│   ├── eyes.json       blink boxes and the blinks' ramp
│   ├── rooms.json      backdrop declarations
│   ├── siren.json      character to Siren Records album
│   └── songs.json      character to official preview
└── scripts/
    ├── fetch-art.mjs       download, cut out, hand off to art-sync
    ├── cutout.mjs          key out a background; split a multi-pose sheet
    ├── art-sync.mjs        measure boxes and accents, write index.json; --watch
    ├── measure-motion.mjs  read a Spine model's animations
    ├── motion-literal.mjs  inline the measured curves into lib/client.js
    ├── siren-sync.mjs      resolve albums and previews
    ├── fetch-rooms.mjs     download backdrops
    ├── chrome.mjs          Chromium discovery, shared by the browser scripts
    ├── check.mjs           the plugin's self-test
    ├── check-site.mjs      drives the console over CDP
    ├── build-site.mjs      generate the console's catalogue and rig
    ├── preview.mjs         render docs/preview*.png from the real code
    └── verify-profile.mjs  pre-flight a live DSH profile

How it works

The DSH GUI is a slot registry. This plugin registers one entry:

shell.overlay: a frame-wide floating layer above every column and outside their scroll containers. It is a list slot, so id: "mascot" adds an entry. The layer is click-through; the sprite opts back into pointer events.

shell.overlay is root-scoped and does not receive useProjection, so the entry declares a session-maybe-scoped child slot (mascot.panel) and renders the panel through props.renderSlot. The renderer then supplies useProjection / useSession / sessionId.

The host half owns one same-origin route prefix:

GET /dsh-mascot/api/balance   account balance, cached
GET /dsh-mascot/api/health    route liveness
GET /dsh-mascot/api/looks     installed looks, rooms, motion, music
GET /dsh-mascot/art/<file>    artwork from the plugin's art/ directory

• The key is resolved per request through ctx.credentials.resolve(), used only as an Authorization: Bearer header, and never appears in a response body, log line or error message.
• Routes are gated on ctx.connection.isAuthenticated(req). Without Connection in the composition they accept only a loopback Host header.
• The artwork route checks path containment, then the extension, then the disk. A missing file is a 404.
• /api/looks re-reads art/index.json per request and drops any look whose files are not on disk.

Where the numbers come from

Every figure in the panel comes from DSH's own session projections. The plugin does not count tokens itself.

• Token breakdown: useProjection("tokenUsage"), shaped { uncachedInputTokens, outputTokens, cacheReadTokens, cacheWriteTokens }
• Cache-hit rate: derived: cacheReadTokens ÷ (uncachedInputTokens + cacheReadTokens + cacheWriteTokens)
• Context occupancy: useProjection("contextPressure"), shaped { contextWindow?, pressureTokens?, projectedTokens? }
• Account balance: /dsh-mascot/api/balance, which calls GET {baseUrl}/user/balance
• Looks, rooms, music: /dsh-mascot/api/looks, reading art/index.json filtered to files on disk

Anything unmeasurable renders as —, not 0.

Development

npm install
npm test                  # 56 checks — fast, no browser
npm run check             # the above, plus the wiring check and a real render
npm run check:render      # renders the mascot in Chromium; fails on any page error
npm run check:site        # 102 checks, drives the console over CDP
npm run check:site -- https://zyaons.github.io/dsh-plugin-mascot/
npm run build:site        # regenerate docs/site/catalog.json and rig.js
npm run preview           # docs/preview.png — placeholder, committed
npm run preview:official  # docs/preview-official.png — official art, gitignored
npm run verify            # pre-flight the current DSH profile

npm test renders nothing, so it cannot see a component that throws while rendering — and a throw in MascotOverlay leaves no mascot at all. npm run check:render mounts the real component in Chromium and fails on any uncaught page error. It caught a return today left over from a return { today, error } refactor: the overlay threw on every render and the mascot vanished, while all the fast checks stayed green.

Run npm run build:site after editing lib/client.js; check:site fails if docs/site/rig.js is out of step with the plugin's own skeleton.

npm test fails if any image under art/ or docs/art/ is tracked by git.

check-site.mjs drives the page over the Chrome DevTools Protocol: clicks are dispatched with Input.dispatchMouseEvent, console errors count as failures, and both file:// and a deployed URL can be checked. The narrow viewport is set through Emulation.setDeviceMetricsOverride rather than --window-size, because a headless window has a minimum width that crops a wider layout.

To add a theme: add a key to THEMES in lib/client.js, add the character's theme in art/looks.json, then add the page theme in all four places — a button in docs/index.html, THEME_COLOURS and PAGE_THEME_NAMES in docs/site/site.js, and a [data-theme="…"] rule in docs/site/site.css. check:site fails if any of the four is missing.

Copyright

The repository contains no artwork belonging to anyone else. Characters are © their owners — Hypergryph (Arknights) and Bushiroad (BanG Dream!). npm run fetch-art downloads the images onto each machine.

• Code: MIT
• Official artwork (art/*.png, not committed): Closure, Muelsyse, Miuyin, Yuyuan, Dusk, Makoto and Wang © Hypergryph; Sengoku Yuno and Sakiko © Bushiroad. Not distributed here. Fine for personal use; get permission before redistributing or using commercially.
• Placeholder: the generic glyph in lib/client.js depicts no character and is MIT.
• DSH: DeepSeek Harness and its @deepseek-ai/* packages belong to their respective authors.

Unofficial fan work, not affiliated with or endorsed by any rights holder.

See COPYRIGHT.md.
