diagram-drift

Detect drift between a Mermaid architecture diagram and the codebase it describes.

架构图漂移检测器：给 Agent 一份 Mermaid 架构图（graph/flowchart）和一个代码库，check 会精准报告「图里画的节点代码里还有没有、图中断言的依赖关系代码里是否成立」。

---

Before / After

Before — An architecture diagram is decoration. Nobody re-checks it against the code, so it slowly lies: a deleted module is still drawn, an edge claims a dependency that no longer exists.

After — A precise drift report: which nodes in the diagram have no matching definition in code, which diagram edges the code doesn't actually honor, and which real modules the diagram forgot to draw.

---

What it does

• check — parse a Mermaid graph/flowchart, scan the codebase for definitions (class/def/module names) and import/call relationships, then classify every node and edge.
• report — re-render the last DRIFT_REPORT.md from the store.
• Output — DRIFT_REPORT.md (human) + drift-state.json (machine-readable, so an agent can read it directly).
• Zero third-party dependencies — pure standard library; Python uses ast, JS/TS/Go and other languages use regex heuristics. No pip install.

Drift types

Type	Meaning	Severity
missing-in-code	A diagram node has no matching definition/module in the code	HIGH
stale-edge	A diagram edge A → B where A does not import/call B	HIGH
missing-in-diagram	A real top-level module is absent from the diagram	INFO
ok	Consistent	—

---

Install

Clone into your agent's skills directory. No pip install required.

Codex

git clone https://github.com/whaojie797-design/diagram-drift ~/.codex/skills/diagram-drift

Claude Code

git clone https://github.com/whaojie797-design/diagram-drift ~/.claude/skills/diagram-drift

Cursor

git clone https://github.com/whaojie797-design/diagram-drift ~/.cursor/skills/diagram-drift

---

Quick start

# 1. point at a diagram (a .md with a ```mermaid block, or a .mmd) and a codebase
python scripts/drift.py check --diagram arch.md --root ./src --store .driftstore

# 2. later, re-check after the code changed
python scripts/drift.py check --diagram arch.md --root ./src --store .driftstore

# 3. re-render the last report
python scripts/drift.py report --store .driftstore

--ignore dir1,dir2 skips extra directories on top of the built-in ignores (node_modules, dist, tests, __pycache__, …).

---

Sample report (real)

$ python scripts/drift.py check --diagram arch.md --root code_drifted --store .ds
Parsed diagram: 5 nodes, 5 edges
[OK]   node — Gateway
[OK]   node — AuthService
[OK]   node — BillingService
[HIGH] node — NotifyService — no definition or module matches 'Notify Service'
[OK]   node — Database
[OK]   edge — Gateway -> AuthService
[OK]   edge — Gateway -> BillingService
[OK]   edge — AuthService -> Database
[OK]   edge — BillingService -> Database
[HIGH] edge — BillingService -> NotifyService — BillingService does not import/call NotifyService
[INFO] module — analytics — module 'analytics' exists in code but is absent from the diagram

5 nodes · 5 edges · 2 drift (HIGH) · 8 consistent

Against a codebase that still matches the diagram, the same command reports 0 drift (HIGH) · 10 consistent.

---

How it works

1. Extract the diagram source (a fenced ```mermaid block, or a raw graph/flowchart string).
2. Parse nodes and edges with a small Mermaid subset parser (square/round/ diamond/cylinder shapes, -->, -.->, ==>, labeled and & chains).
3. Walk the codebase, collecting definitions and per-module import/call tokens. Python via ast; other languages via regex.
4. For each node, check whether any of its id/label tokens matches a code definition or module name. For each edge, check whether the source module actually imports/calls the target. Cross-language name matching normalizes case and separators (AuthService ≡ auth_service).
5. Write DRIFT_REPORT.md + drift-state.json.

Everything is deterministic; the test suite runs entirely against local fixtures (tests/fixtures/code_clean vs code_drifted).

---

Limitations

• It matches on names and import/call tokens, not full data-flow. A node whose name was renamed (but behavior preserved) is still flagged as missing-in-code.
• Edge validation is heuristic: it confirms the source module references the target module/identifier, not that the call is on the specific path drawn.
• Non-Python languages rely on regex; unusual import styles may be missed. Extend scanner.py if you need deeper coverage for a specific language.

---

License

MIT © 2026 whaojie797-design
